Equipment for slicing and stacking FINOVA products

MODULAR SLASTER SliceFil-320

(01) services

«TECHNOWOOD» — are solutions that work. Your technological partner in the world of heat treatment and food processing equipment

MODULAR SLASTER SliceFil-320

15

Number of countries to which we supply our equipment

The Spanish company FINOVA develops and manufactures a high-tech, automated cutting system for meat products.

The new modular slicer SliceFil-320 is characterized by ease of use, compact dimensions, high performance and a wide range of applications, so it can be used in medium-sized production facilities for cooked and smoked sausages, ham, cheese or vegan products. The product is loaded manually and supported by a clamp. Slicing is performed by a circular knife with orbital motion, which allows the product to be sliced with high precision, stacked, staggered or in other presentations.

Calculate the cost

Characteristics: 1. Loading the product onto the polyurethane belt, which prevents damage due to friction during cutting. 2. Manually operated product clamp (optional pneumatic). 3. Cutting system with round blade and independent speed and orbit control. 4. Pneumatically adjustable top and side rammers with adjustable pressure. 5. Product loading gate with gas pistons. 6. The machine is driven by servo motors. 7. Electromechanical security systems on gates and barriers with mechanical locking. 8. The number of slices in each serving may vary depending on your needs, as well as the length of the portions. 9. Stacking height of portions up to 50 mm. 11. Hygienic design for easy cleaning. 12. Quick access to the main functional elements to facilitate system maintenance. 13. Durable construction made of AISI-304 stainless steel. 14. The machine is manufactured in accordance with European Directive 2006/42/CE. 15. Easy setup of all cutting parameters via the integrated 7-inch touchscreen with intuitive menus and icons. 16. Allows you to store up to 50 recipes.

text 6 text 6 text 6

text 7 text 7 text 7

TECHNO WOOD - when quality speaks for itself.

The warranty is 2 years. Delivery all over the world.

text 4 text 4 text 4

text 5 text 5 text 5


Characteristics

Calculate the cost
Productivity
alt

300 cuts/min

Maximum length of the product to be cut
alt

650 mm

Product shaft dimensions (width x height)
alt

250x110 mm

Stacking height
alt

50 mm

The thickness of the slices is adjustable
alt

from 0.5 to 50 mm

Knife diameter
alt

370 mm

Width of the outlet conveyor
alt

280 mm

Air pressure
alt

6 bar

Electrical power
alt

3.8 kW

Voltage
alt

230V - I
